LAA 1215
Manufacturer: American Warming and Ventilating
12" Acoustical Louver with 35% Free Space
Louver Depth12"
DescriptionAcoustical Louver
Free Area5.53 sqft or 35%
Water Penetration1173 fpm (pressure drop velocity only)
Pressure Drop0.13 in w.g at 1173 fpm and 6487 scfm
Frame Material0.080" Thick 6063 T5 Extruded Aluminum
Blades Material0.061" Thick 6063 T5 Extruded Aluminum
Blade Angle45 degrees
Blade Spacing12"
Blade OrientationHorizontal
Screen OptionsBird Screen, Insect Screen
MullionExposed
Miami DadeNo
SightproofNo
